Sale!

Tyro 129 – 7″

(8 customer reviews)

$219.00

The fan-favorite is BACK IN STOCK, at a discounted price!  Parts are getting harder to come by, but we’ve had successes of late.  She’s ready for you to fly!



Category:

Description

CUSTOM-BUILT Tyro129 Long-Range QuadCopter/Drone: BUILT ALREADY! BNF!. Condition is “New”. Shipped with USPS Priority Mail.

Do you wish you didn’t have to BUILD these awesome drones?   All that soldering –and there’s a LOT of soldering: on super tiny pads, too.  So many small parts that get lost, a lack of instructions (Most DIY kits have NO instructions at all) .
And what about your workshop?  You have to maintain so many standard parts, tools, and supplies  Pricey!
Well, here’s the answer:  These are custom-built:  originally DIY drone builds. They’re professionally assembled, fitted, programmed completely in BetaFlight  — calibrated, stabilized, then ONE maiden flight to test all of the functionality.  Once that’s all completed, it’s YOURS to fly!  Add a transmitter and receiver and you’re IN the air.  Add goggles, and you’re FPVing!  Sky’s the limit.
An awesome gift for the enthusiast who just wants to fly, take stunning panoramic videos, freestyle and/or race!
Watch for other models coming soon.  Feel free to make a request for a specific drone and/or build.  They’ll be professionally-built by us!  Just send us a question, as we gradually build up more inventory.
 (NOTE:  If you’re a beginner, we highly recommend you purchase the “ADD-ON” receiver, FrSky R-XSR mini receiver.  It’s what we test all our drones with, and it’s what we fly!  It will be pre-wired to your chosen drone for you!  Then all you’ll need is a radio and a battery!)
Happy Flying!
Today’s build is the infamous Tyro 129 long-range, 7″ quadcopter.  Great fly times, stability, and just plain fun.  Freestyle and/or cruising with FPV, this build is even decked out with GPS at a great price-point!   Be ready for some speed and quickness:  It’s vertical  is amazing!

BrandName: Eachine
Model: Tyro129
Item Name: 280mm F4 OSD DIY Version 7 InchFPV Racing Drone
Version: PNP ( Without Receiver, Battery , RadioTransmitter)



Item Specification
280mm Racing Frame Kit Wheel base: 280mmFrame arm thickness: 5mm

Upper plate thickness: 2mm
Bottom Plate Thickness: 2mm

Side plate thickness: 1.5mm

Frame kit material: 3K carbon fiber
2507 1800KV 3-6S Brushless Motor KV: 1800KVLipo cell: 3-6S

Weight: 39g
Motor Resistance: 0.0586Ω

Maximum pull: 1488g (4S 7inch propeller)

Maximum power: 840W

Configu-ration: 12N/14P
Motor Stator Diameter: 25mm
Motor Stator Thickness: 7mm
Motor Diameter: 30.8mm
Motor Length: 20mm
Whole shaft length: 35mm

Mounting holes distance: 16*16mm

Mounting holes: φM3

Recommend propeller: 6-7 inch
Eachine 4In1 40A BLHeli_S ESC Continuous current: 40ABurst current: 45A (10S)

BEC output: 5V @ 2A

Input voltage: 2-6S

Main control chip: 48mhz EFM8BB2

Firmware upgrade: Supports Dshot150-600/Multishot/Oneshot/PWM
MOS: 5X6
Current Sensor: NO

Size: 37.5×37.5mm
Mounting Hole: 30.5×30.5mm
Weight: 15g
Eachine GPS F4 Flight Controller Brand Name: Eachine
Model: GPS F4
Main control chip: STM32F405Gyroscope: MPU6000
Barometer: BMP280
Firmware: Support betaflight / INAV firmwareIntegrated OSD, support betaflight configuration & DMA Mode ( F4 MCU controls OSD)- Support PPM /DSM2/X / IBUS/ SBUS/ XBUS receiver
– with 10V @ 1.2A BEC Output, for VTX or Camera- LED_STRIP solder pin, changing LED flashing mode &  color via flight controller- Buzzer solder pin, support connect external alarm buzzer- with voltage detection port ( BAT) and current detection port ( CRT), to detect battery’s voltage and current
( Need connect extra current sensor module)
– with MicroSD Blackbox Slot
– with 5 UART & I2C Port, for connecting GPS Module
– Plugs connector / Soldering Pads are Optional for all connector Port
Caddx.us Turbo f2 Camera Case size: 19x19x16mmWeight: 5.5g

Signal system: NTSC / PAL (Switchable)

Resolution ratio(horizontal center): 1200TVL

Video output Signal: cvbs
Image: 16:9

Synchronization method: inter-sync

Camera lens: standard 2.1mm

Lens operating voltage: DC 4.5-40V
S/N Ratio:  >52dB (AGC OFF)
Audio: YES


5.8G 40CH 25/200/600mw switchable VTX

Transmitting power:0/25/200/600mW switchable

Channel: 40CH

Full video format: NTSC/PAL

Input voltage: 7V~24V

Power dissipation: +12V@260mA/600MW
Transmitting Distance: ≥0.5km@25mW, ≥1km@200mW, ≥2km@600mW

Size: 36×36×5mm

Weight: ≤7g (except antenna)


Eachine BN-220 GPS Module Brand Name: Eachine
Model: BN-220
Item Name: BN-220 GPS+GLONASS Dual GPS module
– Built-in FLASH, TTL
Data Protocol:  NMEA-0183
Output Rate: 9600bps, 1HZ
Size: 22mm*20mm*6mm1.TX LED:blue.The data output, TX LED flashing2.PPS LED:red.PPS LED not bright when GPS not fixed,
flashing when fixed
DALProp & Racerstar
T7056C 3-blade propeller		 Brand Name: DALProp
Model: CYCLONE T7056C
Material: PCMounting hole: 5mmColor: Transparent White + Transparent Blue
Quantity: 4 pairs (  Per Color 2 Pairs )
Prop Spiral Diameter: 177.8mm
Hub Thickness: 8.26mmWeight: 7.5g/ PC
Recommend Lipo Battery ( NOT Included) 5S 1600-2200mAh 50-85C Lipo Battery
